Handheld CCD Barcode Scanner

CS-1800

The CS-1800 barcode scanner is a light-weight and high-speed CCD barcode scanner designate for long-lime scanning tasks yet reliability and accuracy are indispensable.

Model		CS-1800
General
Scan Rate		360 scans/sec
Sensor Type		1500 Pixel Linear CCD
Wavelength		590nm, Brilliant Yellow
Depth of Field		0~5 cm (max)
Width of Field		65 mm (contact max.) 80 mm (long distance max.)
Contrast Ratio		45%
Resolution		0.1mm (4 mil)
System Interface		Keyboard Wedge / RS-232 / USB
Indicator		Buzzer and LED illumination
Readable Bar Code Symbologies		Code 39/32, Full ASCII Code 39, Code 128, Code 11, Interleaved 2/5, Industrial 2/5/IATA, Matrix 2/5, China Postage, Code93, MSI/PLESSEY, Codabar/NW7, Code 4, EAN-8/JAN-13, UPC-A, EAN-13/JAN-13, ISBN/ISSN, RSS-14
Others
Power	5VDC ±5%
Material		ABS
Color		Black
Shock Resistance		1.5m drop onto concrete
Compliance		CE, FCC
Weight		155 g
Dimension (L x W x H:mm)		169.2 x 73.8 x 52.3
Cable Length		180 cm
Ambient Light		4500 Lux
Operating Temperature		0°C~50°C
Operating Humidity		20% - 80% RH, non-condensing
Storage Temperature		-20°C~60°C
Storage Humidity		5% - 95% RH, non-condensing
